Fully Automatic Disposable Paper Bowl Making Machine



Main Features of Paper Bowl Making Machine:


1.The advanced open indexing cam structure ensures the stability of the machine.

2. Imported flameless hot air system with stable performance and high production efficiency.

3. The whole machine adopts all-steel frame structure, compact structure and stable operation.

4. All parts and components are manufactured in a standardized way, with strong versatility, good interchangeability and convenient maintenance.

5. The automatic lubrication system is adopted, which can ensure the uninterrupted and high-speed operation of the machine for a long time.

6. Intelligent design, PLC automatic control, servo motor drive, automatic fault alarm, counting, detection, shutdown and other actions, and the data can be easily set on the soft touch screen.




Main Parameters of Paper Bowl Machine


Item Main Specifications
Machine Model FS-BM-A/B/C
Finished Bowls Size Model FS-BM-A FS-BM-B FS-BM-C
Top O.D. Ø90-115 mm Ø90-150mm Ø150-180mm
Bottom I.D. Ø35-100mm Ø75-128mm Ø125-165mm
Height 45-110 45-115mm 45-80mm
Raw Materials Kraft Paper Coating with PE/PLA (Single Side or Double Sides Coating)
Bowls Body: Die-cut sheets
Bowls Bottom: Roll Type
Thickness/GSM of Paper Thickness of Paper:0.345-0.455mm
GSM of Paper: 150-300g/m²
Production Speed 60-70Bowls/min
Cups Body Bonding Way By Ultrasonics Welding Head
Cups Bottom Knurling By Hot-Air Heating
Control System Standard: China Top Brand: Innovance
Mitsubishi Japan can be ordered!
Installation Total Power 11-17KW
Voltage 380V,50Hz,3Phase
220V,50Hz,Signle Phase
Other voltage can be ordered!
Compressor Air Supply 0.6-0.8MPa、0.4m³/min
Prepared by Customer
Machine Size Machine:3000 x 1600x 1900mm
Cups Collection Shelf:
1100 x 600x 1900mm
Machine Weight 2.5TONS


1.Round Bowls Machine:
Model: FS-BM-A



2.Round Paper Bowls Making Machine:Model-B



3.Round Paper Bowls Making Machine:Model-C




4.Rectangle Paper Bowls Making Machine:




5.Automatic Paper Bowls Lids /Covers Making Machine:
