FS-PB Fully Automatic Plastic Bag Packaging Machine

Application:
For packaging medicines, daily necessities, food, hardware, fruits, vegetables, etc.

Main Features:
1. Equipped with three sets of servo systems, the bag length can be set and cut immediately, no need to adjust the idling, and it can be done in one step, saving time and film.
2. Human-machine interface, parameter setting is convenient and quick.
3. Fault self-diagnosis function, fault display is clear briefly.
4. High-sensitivity photoelectric eye color mark tracking, digital input of sealing and cutting position, so that the sealing and cutting position is more accurate.
5. Temperature independent PID control, better suitable for various packaging materials.
6. Positioning stop function, no sticking to the knife, no waste of film.
7. The transmission system is simple, the work is more reliable, and the maintenance is more convenient.
8. All controls are realized by software, which is convenient for function adjustment and technical upgrade.

Main Specification:

Model	FS-PB250	FS-PB350	FS-PB450	FS-PB600
Finished Bag Length	70-280mm	70-300mm	70-400mm	70-500mm
Finished Bag Width	30-110mm	50-160mm	50-210mm	50-280mm
Finished Bag Height	40-60mm	70-300mm	70-400mm	70-500mm
Plastic Film Max Width	≤250mm	≤350mm	≤450mm	≤600mm
Plastic Film Max Diameter	≤Ø320mm	≤Ø320mm	≤Ø320mm	≤Ø320mm
Film Materials	BOPP, PE, PET, OPP etc..
Packing Speed	40-200bag/min	40-200bag/min	40-180Bag/min	40-100Bag/min
Voltage:220V,50Hz/60Hz	2.6KW	2.8KW	3.2KW	3.5KW
Machine Size(mm)	3900X680X1400	6900x850x1400	4100x900x1500	4100x900x1500
Machine Weight	450KGS	580KGS	650KGS	700KGS
